Data Sheet
ADP5070
Rev. A | Page 7 of 27
Pin No.
Mnemonic
Description
LFCSP
TSSOP
18
20
SW2
Switching Node for the Inverting Regulator.
19
1
PGND
Power Ground for the Boost and Inverting Regulators.
20
2
SW1
Switching Node for the Boost Regulator.
EPAD
Exposed Pad. Connect the exposed pad to AGND.
