INCHANGE Semiconductor
isc Product Specification
isc website：www.iscsemi.com
isc & iscsemi is registered trademark
2
isc Silicon NPN Power Transistor
2SC3085
ELECTRICAL CHARACTERISTICS
TC=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP.
MAX
UNIT
V(BR)CEO
Collector-Emitter Breakdown Voltage
IC= 1mA; RBE= ∞
400
V
V(BR)CBO
Collector-Base Breakdown Voltage
IC= 1mA; IE= 0
500
V
V(BR)EBO
Emitter-Base Breakdown Voltage
IE= 1mA; IC= 0
7
V
VCE(sat)
Collector-Emitter Saturation Voltage
IC=16A; IB= 3.2A
1.0
V
VBE(sat)
Base-Emitter Saturation Voltage
IC= 16A; IB= 3.2A
1.5
V
ICBO
Collector Cutoff Current
VCB= 400V; IE=0
10
μ
A
IEBO
Emitter Cutoff Current
VEB= 5V; IC=0
10
μ
A
hFE-1
DC Current Gain
IC= 3.2A; VCE= 5V
15
50
hFE-2
DC Current Gain
IC= 16A; VCE= 5V
8
COB
Output Capacitance
IE= 0; VCB= 10V; ftest=1.0MHz
320
pF
fT
Current-Gain—Bandwidth Product
IC= 3.2A; VCE= 10V
20
MHz
hFE-1 Classifications
L
M
N
15-30
20-40
30-50
