 2 / 2 page
background image
INCHANGE Semiconductor
isc Product Specification
2
isc website：www.iscsemi.com
isc & iscsemi is registered trademark
isc Silicon NPN Power Transistor
TIP35CF
ELECTRICAL CHARACTERISTICS
TC=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
MAX
UNIT
*VCEO(SUS) Collector-Emitter Sustaining Voltage
IC= 30mA; IB= 0
100
V
*VCE(sat)-1 Collector-Emitter Saturation Voltage
IC= 15A; IB= 1.5A
1.8
V
*VCE(sat)-2 Collector-Emitter Saturation Voltage
IC= 25A; IB= 5A
4.0
V
*VBE(on)-1
Base-Emitter On Voltage
IC= 15A ; VCE= 4V
2.0
V
*VBE(on)-2
Base-Emitter On Voltage
IC= 25A ; VCE= 4V
4.0
V
ICEO
Collector Cutoff Current
VCE= 60V; IB= 0
1.0
mA
ICBO
Collector Cutoff Current
VCB= 100V; IE= 0
0.7
mA
IEBO
Emitter Cutoff Current
VEB= 5V; IC= 0
1.0
mA
*hFE-1
DC Current Gain
IC= 1.5A ; VCE= 4V
25
*hFE-2
DC Current Gain
IC= 15A ; VCE= 4V
15
75
fT
Current-Gain—Bandwidth Product
IC= 1A ; VCE= 10V;ftest= 1.0MHz
3
MHz
*Pulse test: Pulse width 300µs, Duty cycle <2%
