Table 70. CANIDT1 Register for V2.0 part A

CANIDT1 for V2.0 part A (S:BCh) – CAN Identifier Tag Registers 1

No default value after reset.

Table 71. CANIDT2 Register for V2.0 part A

CANIDT2 for V2.0 part A (S:BDh)

– CAN Identifier Tag Registers 2

No default value after reset.

Table 72. CANIDT3 Register for V2.0 part A

CANIDT3 for V2.0 part A (S:BEh) –CAN Identifier Tag Registers 3

No default value after reset.

765

43210

IDT 10

IDT 9

IDT 8

IDT 7

IDT 6

IDT 5

IDT 4

IDT 3

Bit Number

Bit Mnemonic

Description

7 - 0

IDT10:3

IDentifier Tag Value

See Figure 43.

765

43210

IDT 2

IDT 1

IDT 0

-----

Bit Number

Bit Mnemonic

Description

7 - 5

IDT2:0

IDentifier Tag Value

See Figure 43.

4-0

Reserved

The values read from these bits are indeterminate. Do not set these

bits.

765

43210

--------

Bit Number

Bit Mnemonic

Description

7 - 0

Reserved

The values read from these bits are indeterminate. Do not set these

bits.
