CPC3909

7

CPC3909ZTR Tape & Reel

MECHANICAL DIMENSIONS

CPC3909CTR Tape & Reel

Dimensions

mm

(inches)

Embossment

Embossed

Carrier

177.8 Dia

(7.00 Dia)

Top Cover

Tape Thickness

0.102 Max

(0.004 Max)

W=12.00 ± 0.3

(0.472 ± 0.012)

B

(0.181 ± 0.004)

A

(0.189 ± 0.004)

P=8.00 ± 0.1

(0.315 ± 0.004)

K

(0.071 ± 0.004)

2.00 ± 0.05

(0.079 ± 0.002)

4.00 ± 0.1

(0.157 ± 0.004)

1.75 ± 0.1

(0.069 ± 0.004)

5.50 ± 0.05

(0.217 ± 0.002)

Dimensions

mm

(inches)

Embossment

Embossed

Carrier

177.8 Dia

(7.00 Dia)

Top Cover

Tape Thickness

0.102 Max

(0.004 Max)

W=12.08 ± 0.2

(0.476 ± 0.008)

B

(0.292 ± 0.004)

A

(0.269 ± 0.004)

P=8.03 ± 0.1

(0.316 ± 0.004)

K

(0.074 ± 0.004)

2.00 ± 0.05

(0.079 ± 0.002)

4.00 ± 0.1

(0.157 ± 0.004)

1.75 ± 0.1

(0.069 ± 0.004)

5.50 ± 0.05

(0.217 ± 0.002)
