Product Search Data Sheet

SFSKB3M20FF00-R1

Appearance & Shape

Applications

Other Usage

Audio Visual Equipment

Packaging Information

Packaging

Specifications

Minimum

Order Quantity

-R0

330mm Embossed Tape

3000

Features

The SFSKB series are SMD ceramic filters suitable for IR

headphone applications. Center frequencies of 2.3, 2.8, 3.2, 3.8, 4.3,

4.8, 5.2, 5.7MHz are available. Realized small, thin and lightweight

package, compared with conventional LC filters. It helps to compose

multi-channel circuit on one PCB. No frequency adjustment is

required on PCB and it contributes to the reduction of production

cost.

Features

1. SMD package in plastic emboss tape, available for automatic

placing.

2. They are slim, at only 1.5mm max. thickness, and have a small

mounting area (5.2x3.8mm) enabling flexible PCB design.

3. Available for lead (Pb) free reflow soldering process.

4. Operating temperature range: 0 to +70 (degrees C), Storage

temperature range: -55 to +85 (degrees C)

5. No frequency adjustment is required in production process.

6. Small, thin and lightweight package compared with conventional

LC filters.

1 of 3

Atten ti o n

1.T his datasheet is downloaded from the website of Murata Manufacturing Co., Ltd. T herefore, it’s specifications are subject to change or our products in it may be discontinued

without advance notice. Please check with our sales representatives or product engineers before ordering.

2.T his datasheet has only typical specifications because there is no space for detailed specifications.

T herefore, please review our product specifications or consult the approval sheet for product specifications before ordering.

URL : http://www.murata.com/

Last

：

updated 2016/06/24
