background image
LNBH26LS
I²C interface protocol
DocID025504 Rev 1
21/33
7.3
Data registers
The DATA 1..4 registers can be addressed both to write and read mode. In read mode they
return the last writing byte status received in the previous write transmission.
The following tables provide the register address values of DATA 1..4 and a function
description of each bit.
Table 6: DATA 1 (read/write register. Register address = 0X2)
Bit
Name
CH
Value
Description
Bit 0
(LSb)
VSEL1-
A
A
0/1
Channel A
output voltage selection bits.
(Refer to Table 13: "Output voltage selection table (data1
register, write mode)")
Bit 1
VSEL2-
A
0/1
Bit 2
VSEL3-
A
0/1
Bit 3
VSEL4-
A
0/1
Bit 4
VSEL1-
B
B
0/1
Channel B
output voltage selection bits.
(Refer to Table 13: "Output voltage selection table (data1
register, write mode)")
Bit 5
VSEL2-
B
0/1
Bit 6
VSEL3-
B
0/1
Bit 7
(MSb)
VSEL4-
B
0/1
N/A = reserved bit.
All bits reset to “0” at power-on.
Table 7: DATA 2 (read/write register. Register address = 0X3)
Bit
Name
CH
Value
Description
Bit 0
(LSb)
TEN A
A
1
22 kHz tone enabled. Tone output controlled by the DSQIN
pin
0
22 kHz tone output disabled
Bit 1
N/A
0
Reserved. Keep to “0”.
Bit 2
EXTM-
A
1
DSQIN input pin is set to receive external 22 kHz TTL signal
source
0
DSQIN input pin is set to receive external DiSEqC envelope
TTL signal
Bit 3
N/A
0
Reserved. Keep to “0”.
Bit 4
TEN-B
B
1
22 kHz tone enabled. Tone output controlled by the DSQIN
pin
0
22 kHz tone output disabled
Bit 5
N/A
0
Reserved. Keep to
“0”.
Bit 6
EXTM-
B
1
DSQIN input pin is set to receive external 22 kHz TTL signal
source
