background image
 2010 - 2015 Microchip Technology Inc.
DS00001979A-page 41
USB224X
PRODUCT IDENTIFICATION SYSTEM
To order or obtain information, e.g., on pricing or delivery, refer to the factory or the listed sales office
.
Device:
USB2240, USB2240I, USB2241, USB2241I,
USB2244, USB2244I
Temperature
Range:
Blank
= 0
°C to +70°C (Extended Commercial)
I= -40
°C to +85°C (Industrial)
Package:
AEZG
= 36-pin QFN
Tape and Reel
Option:
Blank
= Standard packaging (tray)
TR
= Tape and Reel (1)
Note
1:
Tape and Reel identifier only appears in the catalog part number descrip-
tion. This identifier is used for ordering purposes and is not printed on the
device package. Check with your Microchip Sales Office for package
availability with the Tape and Reel option. Reel size is 3,000.
PART NO.
[X]
XXX
Package
Temperature
Range
Device
[X]
-
[X]
Internal Microchip Tape & Reel
Code
Option
-
-
Examples:
a)
USB2240-AEZG-06 36-pin QFN RoHS Compli-
ant pkg, Commercial Temp, Tray
b)
USB2240-AEZG-05 36-pin QFN RoHS Compli-
ant pkg, Commercial Temp, Tray
c)
USB2241-AEZG-06 36-pin QFN RoHS Compli-
ant pkg, Commercial Temp, Tray
d)
USB2241-AEZG-05 36-pin QFN RoHS Compli-
ant pkg, Commercial Temp, Tray
e)
USB2244-AEZG-06 36-pin QFN RoHS Compli-
ant pkg, Commercial Temp, Tray
f)
USB2244-AEZG-06-CA1 36-pin QFN RoHS
Compliant pkg, Commercial Temp, Tray
g)
USB2240I-AEZG-06 36-pin QFN RoHS Compli-
ant pkg, Industrial Temp, Tray
h)
USB2241I-AEZG-06 36-pin QFN RoHS Compli-
ant pkg, Industrial Temp, Tray
i)
USB2241I-AEZG-06 36-pin QFN RoHS Compli-
ant pkg, Industrial Temp, Tray
j)
USB2240-AEZG-06-TR
36-pin
QFN
RoHS
Compliant pkg, Commercial Temp, Tape & Reel
k)
USB2244I-AEZG-06-TR
36-pin
QFN
RoHS
Compliant pkg, Industrial Temp, Tape & Reel
