Fiber Optic Receiving Module

Features

High PD Sensitivity Optimized for Red Light

Data Rate between 100Kbps and 16Mbps

Low Power Comsumption for

Extended Battery Life

Built-in Threshold Control for

Improved Noise Margin

2 pin Cap Housing

Applications

Digital Optical Data-Links

Dolby AC-3 Digital Audio Interface

Amplifier

Absolute Maximum Ratings

[Ta = 25 ]

*1 : Soldering Time

10 seconds(At a distance of 1mm from the package)

Electro-Optical Characteristics

[Vcc= 5V, Ta= 25 ]

Jitter

tj

MAX 25 ns

-

tw

MAX 15 ns

-

Fall Time

tr

MAX 15 ns

-

Pulse Width Distortion

Rise Time

tr

MAX 15 ns

-

Propagation Delay Time ( L -> H )

t pLH

MAX 100 ns

-

Propagation Delay Time ( H -> L )

t pHL

MAX 100 ns

-

Low Level Output Voltage

VOL

MAX 0.4 V

-

High Level Output Voltage

VOH

MIN 2.4 V

-

Current Consumption

ICC

MAX 6.0 mA

-

Optical Output Coupling with Fiber

Pc

MIN -24 dBm

-

Data Rate

T

TYP 16 Mbps

-

Peak Emission Wavelength

p

TYP 700 nm

-

Operating Supply Voltage

Vcc

4.75 ~ 5.25 V

-

Parameter

Symbol

Characteristics

Condition

Description

Symbol

Ratings

Condition

Power Supply Voltage

Vcc

-0.5 ~ +7.0

-

Topr

-20 ~ +70

-

Input Voltage

VIN

Vcc+0.3V

-

KFO-RX16CB

Soldering Temperature *1

Tsol

260

-

Storage Temperature

Vstg

- 30 ~ + 80

-

Operating Temperature

Dimensions

(Unit : )

1/1
