series 28

HiPer-D Combo Connectors

C

.170 (4.32)

.250 (6.35)

.040±.040 (1.02±1.02)

DIAMETRAL FLOAT

CONNECTOR

FLOAT BUSHING

.120 (3.05)

SECTION A-A

C

C

E

D

B

A

G

R .100 (2.54)

GUIDE PIN, GUIDE BUSHING, OR 8-32

UNC 2B .150 (3.81) MIN. DEEP 2PLCS

A

A

4-40 UNC-2B

.150 (3.81) MIN. DEEP

TYP 2 PLCS

.390

(9.91)

.266

(6.76)

.243±.005

(6.17±0.13)

.094 (2.39)

H

OPTIONAL SEALING BOOT SUPPLIED WITH

CONTACT OR ORDERED SEPARATELY

1.110 (28.19)

(REF)

Shell

Size

A

B

C Basic

E

G Basic

H

in

± .015

mm

± 0.38

in

± .015

mm

± 0.38

in.

mm

in

± .005

mm

± 0.13

in

mm

in

± .005

mm

± 0.13

1

1.986 50.44

.494 12.55

.984 24.99

.311

7.90 1.636 41.55 1.213 30.81

2

2.314 58.78

.494 12.55 1.312 33.32

.311

7.90 1.964 49.89 1.541 39.14

3

2.854 72.49

.494 12.55 1.852 47.04

.311

7.90 2.504 63.60 2.081 52.86

4

3.502 88.95

.494 12.55 2.500 63.50

.311

7.90 3.152 80.06 2.729 69.32

5

3.408 86.56

.600 15.24 2.406 61.11

.423 10.74 3.058 77.67 2.635 66.93

280-059S DIMENSIONS

280-059S float mount combo socket connectors for blind mating, crimp

termination

NOTES

1.

widest selection of plating options with no minimum order quantities or setup charges.

2.

3.

section for contact part numbers, specifications, crimp tool information, and insertion/extraction tools.

4.

crimp tool information, and insertion/extraction tools.

5.

Combo HiPer-D connectors meet the applicable requirements of MIL-DTL-24308 and are intermateable with standard non-

environmental D Subminiature connectors with corresponding contact arrangements and type. Size 8 contacts from other

manufacturers cannot be installed in HiPer-D connectors.

6.
