UNISONIC TECHNOLOGIES CO., LTD

UD3K

DUAL TRANSISTOR

www.unisonic.com.tw

1 of 4

Copyright © 2010 Unisonic Technologies Co., Ltd

QW-R218-004.B

GENERAL PURPOSE

(DUAL DIGITAL TRANSISTOR)

FEATURES

* Both the DTA114E chip and DTC114E chip in a SOT-363 package.

* NPN/PNP silicon transistor(Built-in resistor type)

EQUIVALENT CIRCUIT

1

2

3

45

6

R1

R1

TR1

TR2

R2

R2

SOT-363

4

5

3

2

1

6

ORDERING INFORMATION

Pin Assignment

Ordering Number

Package

12

34

56

Packing

UD3KG-AL6-R

SOT-363

G

I

O

G

I

O

Tape Reel

Note: G: GND, I: Input, O: Output

MARKING
