UCD40106B
Preliminary
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
4 of 6
www.unisonic.com.tw
QW-R502-815.d
DYNAMIC CHARACTERISTICS (TA =25°C, unless otherwise specified; Input: tR, tF=20ns)
See Fig. 1 and Fig. 2 for test circuit and waveforms.
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX UNIT
Propagation delay from input
(A) to output(Y)
tPLH/tPHL
VCC=5V, CL=50Pf, RL=200KΩ
140
280
ns
VCC=10V, CL=50Pf, RL=200KΩ
70
140
VCC=15V, CL=50Pf, RL=200KΩ
60
120
Output Transition Time
tTLH/tTHL
VCC=5V, CL=50Pf, RL=200KΩ
100
200
ns
VCC=10V, CL=50Pf, RL=200KΩ
50
100
VCC=15V, CL=50Pf, RL=200KΩ
40
80
OPERATING CHARACTERISTICS
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX UNIT
Average Input Capacitance
CIN
Any Input
5
7.5
pF
Power Dissipation Capacitance
CPD
Any Gate
14
pF
