No. de pieza	CONMCX007-R178

Descripción Electrónicos	MCX MALE CABLE END CRIMP FOR RG178 CABLE

PDF	1 Pages

Scroll/Zoom	100%

Fabricante Electrónico	ETC2 [List of Unclassifed Manufacturers]

Página de inicio

Logo

1 / 1 page

A

B

C

D

4

3

2

1

D

C

B

A

1

2

4

3

Description

Material

Finish

Body

Insulation

Gold

Teflon

Gold

Teflon

Brass

CONNECTOR CITY

159 ORT LANE

MERLIN, OR 97532

PH (541)-471-6256

FAX (541)-471-6251

Date:

Sheet 1 of 1

Revision:

Title

Part No.

Dimensions:

MCX MALE CABLE END CRIMP

FOR RG178 CABLE

CONMCX007-R178

1.0

INCHES (mm)

6/8/2006

0.236

(6.00)

0.020

(0.50)

RECOMMENDED CABLE STRIPPING DIMENSIONS

0.110

(2.80)

RG-178 Cable

CONMCX007-R178 ASSEMBLY INSTRUCTIONS

Snaps

Gold

BE CU

Ø0.037

(0.95)

0.232

(5.90)

Ø0.019

(0.48)

Ø0.020

(0.5)

Ø0.106

(2.70)

0.197

(5.00)

0.488

(12.40)

Ø0.197

(5.00)

Ø0.148

(3.75)

0.126

(3.20)

0.165

(4.20)

BOYD CHUCK

0.3x3.9x5 GROOVE

Spacer

Teflon

SIDE VIEW

SPACER

SUPPORT

Support

Gold

Brass

1. Strip the cable to the recommended dimensions.

2. Solder the support onto the braid.

3. Place the spacer onto the center conductor.

4. Solder or crimp the pin onto the center conductor.

5. Insert the pin, center conductor, spacer, and support into the body

until the pin snaps in.

6. Crimp the tail of the body onto the support with a hex crimp tool.
