BCP53_BCX53_BC53PA

All information provided in this document is subject to legal disclaimers.

Product data sheet

Rev. 9 — 19 October 2011

5 of 22

NXP Semiconductors

BCP53; BCX53; BC53PA

80 V, 1 A PNP medium power transistors

(1) FR4 PCB, mounting pad for collector 6 cm2

(2) FR4 PCB, mounting pad for collector 1 cm2

(3) FR4 PCB, standard footprint

(1) FR4 PCB, mounting pad for collector 6 cm2

(2) FR4 PCB, mounting pad for collector 1 cm2

(3) FR4 PCB, standard footprint

Fig 1.

Power derating curves SOT223

Fig 2.

Power derating curves SOT89

(1) FR4 PCB, 4-layer copper, mounting pad for collector 1 cm2

(2) FR4 PCB, single-sided copper, mounting pad for collector 6 cm2

(3) FR4 PCB, single-sided copper, mounting pad for collector 1 cm2

(4) FR4 PCB, 4-layer copper, standard footprint

(5) FR4 PCB, single-sided copper, standard footprint

Fig 3.

Power derating curves SOT1061

Tamb (°C)

–75

175

125

–25

006aac674

0.5

1.0

1.5

Ptot

(W)

0.0

(1)

(2)

(3)

Tamb (°C)

–75

175

125

–25

006aac675

0.5

1.0

1.5

Ptot

(W)

0.0

(1)

(2)

(3)

Tamb (°C)

–75

175

125

–25

006aac676

1.0

0.5

1.5

2.0

Ptot

(W)

0.0

(1)

(2)

(3)

(4)

(5)
