2

Storage Temperature Range

Junction Temperature

Case Operating Temperature Range

MSK4853H

MSK4853

-55°C to +125°C

150°C

-55°C to +125°C

-40°C to +85°C

Collector to Emitter Voltage

Gate to Emitter Voltage

Current (Continuous)

Current Pulsed (1mS)

Case Isolation Voltage

ELECTRICAL SPECIFICATIONS

ABSOLUTE MAXIMUM RATING

600V

±20V

150A

300A

2500 V

NOTES:

Guaranteed by design but not tested. Typical parameters are representative of actual device performance but are for reference only.

Industrial grade devices shall be tested to subgroup 1 unless otherwise specified.

HI-REL grade devices ("H" suffix) shall be 100% tested to subgroups 1, 2 and sample tested to subgroup 3.

Subgroup 4 testing available upon request.

Subgroup 1, 4

3

All specifications apply to both the upper and lower sections of the half bridge.

Continuous operation at or above absolute maximum ratings may adversly effect the device performance and/or life cycle.

Internal solder reflow temperature is 180°C, do not exceed.

1

2

3

4

5

6

7

8

9

8

8548-20 Rev. F 12/14

9
