Power Shielded Inductor

PS80

15

ALLIED COMPONENTS INTERNATIONAL

714-665-1140

www.alliedcomponents.com

RoHS

1/18/13

Features

• SMD Ultra High Current up to 45A

Electrical

Inductance Range:

.33µH to 1.2µH additonal

Tolerance:

20% over entire range

Pre-Heat 150ºC, 1 minute.

Test Equipment

(L):

WK 4237 Meter

• Magnetically Shielded Construction

Resistance to Soldering Heat

Solder Composition:

Sn/Ag3.0/Cu0.5

Solder Temp:

260ºC ± 5ºC

DCR:

HK502BS Meter

Temp. Rise:

=40ºC Typical at rated Irms without

without core loss.

Test Frequency

: 100KHz

• Designed for low buzz noise

• Low DC Resistance

Immersion Time:

10 sec. ± 1 sec.

Part temperature should not exceed 125ºC

including temperature rise.

• Suitable for pick and place

values available.

Inductance drop: 30% typical at rated Isat

Physical

Packaging:

500 pieces per 13 inch reel.

Marking:

EIA Inductance Code

Isat/Irms:

3260B WK & DC Bias 3265B WK

All specifications subject to change without notice.

Allied

Part

Number

Inductance

(

µH)

Irms

(

A) Max

Test

Frequency

(KHz, 0.5V)

Tolerance

(±%)

RDC

PS80-R33M-RC

PS80-R47M-RC

PS80-R56M-RC

PS80-R68M-RC

PS80-R82M-RC

PS80-1R0M-RC

PS80-1R2M-RC

Isat

(A) Max

.33

.47

.56

.68

.82

1.0

1.2

2.7

3.1

4.2

5.8

20

100

45

40

3

0

24

21

19

16

22

20

18

15

∆

Available in tighter tolerances

Dimensions:

Inches

(mm)

Operating Temp:

-25ºC to +85ºC
