SMD High Current Shielded Choke

PCHC412R8

15

ALLIED COMPONENTS INTERNATIONAL

714-665-1140

www.alliedcomponents.com

RoHS

07/23/2013

Features

• Magnetically shielded construction

Electrical

Inductance Range:

.22µH to 4.7uH additonal

Tolerance:

20% over entire range

Operating Temp:

-55ºC ~ +125ºC

Pre-Heat 150ºC, 1 minute.

Test Equipment

(L):

WK 3260B

• Ultra High saturation current up to 11.5A

Resistance to Soldering Heat

Solder Composition:

Sn/Ag3.0/Cu0.5

Solder Temp:

260ºC ± 5ºC

DCR:

Chen HWA502

Temp. Rise:

=40ºC Typical at heat rated

Test Frequency

: 100KHz, 0.5Vdc

• Low RD Resistance

• Expanded operating temp range

Immersion Time:

10 sec. ± 1 sec.

Under no condition should the part exceed

.162+/-.008

(4.1+/-0.2)

(4.6±0.2)

.181±.008

(1.2)

.047

(1.5±0.3)

.06±.012

.04+/-.02

(1.0+/-0.5)

125ºC.

• Suitable for pick and place

values available.

Inductance drop: 30% typical at rated Isat

Physical

Packaging:

2000 pieces per 13 inch reel.

Marking:

EIA Inductance Code

IDC:

3260B WK & DC Bias 3265B WK

All specifications subject to change without notice.

Allied

Part

Number

Inductance

(

µH)

Irms

(A)

Test

Frequency

(KHz, 0.5V)

Tolerance

(±%)

RDC

(mΩ)

PCHC412R8-R22M-RC

Isat

(A)

0.22

12

20

100

11.5

8.5

∆

(Recommended Solder Pads)

.099

(2.5)

.059

(1.5)

.146

(3.7)

Typ

Max

Storage Temp:

-55ºC ~ +125ºC

current.

PCHC412R8-R47M-RC

0.47

25

20

100

7.0

5.0

PCHC412R8-R68M-RC

0.68

37

20

100

6.0

4.0

PCHC412R8-1R0M-RC

1.0

46

20

100

5.2

4.0

PCHC412R8-2R2M-RC

2.2

114

20

100

3.5

2.2

PCHC412R8-4R7M-RC

4.7

195

20

100

2.8

1.8

Inductance vs DC Current

0

0.5

1

1.5

2

2.5

3

3.5

4

4.5

5

0

1

2

3

4

5

67

8

9

10 11

12 13 14 15

16 17

DC Current(A)

R22

R47

R68

1R0

2R2

4R7

Tem perature Change v.s DC Current

0

20

40

60

80

100

120

140

012345678

9

10

11

12

13

1R0

R68

R22

R47

2R2

4R7

Dimensions:

Inches

(mm)

MAX
