SmartSwitchTM
OLED Display
www.nkk.com
E4
E
Driving Block
SEG/COM
Segment Driver
SR1,SG1,SB1......SR52,
SG52,SB52
Color OLED Panel
52RGB x 36
Gray Scale
Common Driver
COM1....COM36
Display Timing
Oscillator
Generator
Decoder
Command Decoder
Graphic Display
Data
RAM
96 x 64 x 16 Bit
MCU Interface
OLED Driver
with Controller
CC
V
7
DD
V
1
RES
3
SCK
5
2
SS
6
SDI
4
D/C
GND 8
TYPICAL DISPLAY DIMENSIONS
DISPLAY BLOCK DIAGRAM & PIN CONFIGURATIONS
(2.0)
.079
(1.0)
.039
(7.0)
.276
(14.7)
.579
(0.65)
.026
(10.0)
.394
Typ
(5.25)
.207
Typ
(0.4)
.016
Typ
(15.0)
.591
(15.0)
.591
(14.7)
.579
(10.0)
.394
(16.8)
.661
(1.0)
.039
Typ
(2.0)
.079
(5.25)
.207
(7.0)
.276
1
2
7
8
8x (.075) Dia
.029
3x (0.9) Dia
.035
Landless
4x (0.9) Dia
.035
(17.2)
.677
(9.9)
.390
(17.8)
.701
(12.9)
.508
(0.75)
.030
See
Pixel Detail
(10.89)
(7.89)
.311
.429
ISC01P
Terminal numbers are not on the switch.
Pin No.
Symbol
Name
Function
VDD
Power
Power source for logic circuit
SS
Slave Select
Slave select for SPI. This line is active low.
RES
Reset
Reset signal input. When pin is low, initialization of chip is
executed.
D/C
Data/Command
Data/Command Control. When pin is pulled low, data will
be interpreted as Command; when pulled high, data will be
interpreted as Data.
SCK
Serial Clock
Clock line for SPI that synchronizes command and data
SDI
Serial Data In
Data input line for SPI
VCC
Power
Power source for drive circuit
GND
Ground
Connect to Ground
6
5
4
3
2
1
8
7
Pixel Detail
Pixel Detail A
Footprint
R
R
G BR
(0.19)
.0075
(0.22)
.0087
(0.04) Typ
.0016
(0.07) Typ
.0028
(0.21)
.0083
(0.03)
.0012
Typ
(0.03) Typ
.0012
(0.21) Typ
.0083
See Pixel
Detail A
(0.22) Typ
.0087
(9.9)
.390
(3.0)
.118
(16.8)
.661
(0.4)
.016
Typ
(0.7)
.028
(2.0)
.079
See Standoff
Detail
(0.2)
.008
(0.2)
.008
(0.8) Dia
.031
(1.5) Dia
.059
(0.7)
.028
Standoff Detail
