CSM_EE-SPY31_41_DS_E_3_1

Light Convergent Reflective Photomicrosensor

EE-SPY31/41

Accurately detects objects placed in

front of shiny Background.

• A shiny background can be used as long as the distance between

the sensor and the background is 20 mm or more.

• Detects minute objects such as a 0.05-mm-dia. pure copper wire.

• Small dispersion in sensing distance.

• Light modulation effectively reduces external light interference.

• Wide operating voltage range: 5 to 24 VDC

Be sure to read Safety Precautions on

page 4.

Ordering Information

Sensors

Accessories (Order Separately)

* Refer to Accessories for details.

Appearance

Sensing method

Sensing distance

Output type

Output

configuration

Model

Convergent

reflective type

NPN output

Dark-ON

EE-SPY311

Light-ON

EE-SPY411

Dark-ON

EE-SPY312

Light-ON

EE-SPY412

Type

Cable length

Model

Connector

EE-1001

EE-1009

Connector with Cable

1 m

EE-1006

EE-1010

2 m

EE-1006

EE-1010

Connector with Robot

Cable

1 m

EE-1010-R

2 m

EE-1010-R

NPN/PNP Conversion Connector

0.46 m (total length)

EE-2002

Infrared light

Horizontal

type

2 to 5 mm

Vertical

type
