ADT7420

Data Sheet

Rev. 0 | Page 4 of 24

Parameter

Min

Typ

Max

Unit

Test Conditions/Comments

Shutdown Current

At 3.3 V

2.0

15

µA

Supply current in shutdown mode

At 5.5 V

5.2

25

µA

Supply current in shutdown mode

Power Dissipation Normal Mode

700

µW

Power Dissipation 1 SPS

150

µW

1

Accuracy specification includes repeatability.

2

The equivalent 3 σ limits are ±0.15°C. This 3 σ specification is provided to enable comparison with other vendors who use these limits.

3

For higher accuracy at 5 V operation, contact Analog Devices, Inc.

4

Temperature Hysteresis does not include repeatability.

5

Based on a floating average of 10 readings.

6

Drift includes solder heat resistance and life time test performed as per JEDEC Standard JESD22-A108.
