MPX2053

Rev 9, 10/2012

Freescale Semiconductor

Data Sheet: Technical Data

© 2005-2009, 2012 Freescale Semiconductor Inc. All rights reserved.

Pressure

50 kPa On-Chip Temperature

Compensated and Calibrated

Silicon Pressure Sensors

The MPX2053 series devices are silicon piezoresistive pressure sensors

that provide a highly accurate and linear voltage output directly proportional to the

applied pressure. A single, monolithic silicon diaphragm with the strain gauge and

an integrated thin-film resistor network. Precise span and offset calibration with

temperature compensation are achieved by laser trimming.

Features

•

Temperature Compensated Over 0

C to +85C

•

Easy-to-Use Chip Carrier Package Options

•

Ratiometric to Supply Voltage

•

Gauge Ported and Non Ported Options

•

Available in Easy-to-Use Tape & Reel

•

Differential and Gauge Pressure Options

ORDERING INFORMATION

Device Name

Case No.

# of Ports

Pressure Type

Device Marking

None

Single

Dual

Gauge

Differential

Absolute

Small Outline Package (MPXV2053G Series)

MPXV2053GP

1369

•

•

MPXV2053GP

MPXV2053DP

1351

•

•

MPXV2053DP

Unibody Package (MPX2053 Series)

MPX2053D

344

•

•

MPX2053D

MPX2053DP

344C

•

•

MPX2053DP

MPX2053GP

344B

•

•

MPX2053GP

MPAK Package (MPXM2053 Series)

MPXM2053D

1320

•

•

MPXM2053D

MPXM2053DT1

1320

•

•

MPXM2053D

MPXM2053GS

1320A

•

•

MPXM2053GS

MPXM2053GST1

1320A

•

•

MPXM2053GS

MPX2053

Series

0 to 50 kPa (0 to 7.25 psi)

40 mV Full Scale

(Typical)

Application Examples

•

Pump/Motor Control

•

Robotics

•

Level Detectors

•

Medical Diagnostics

•

Pressure Switching

•

Blood Pressure Measurement
