 2 / 3 page
background image
SK24
DIODE
UNISONICTECHNOLOGIESCO.,LTD
2 of 3
www.unisonic.com.tw
QW-R601-041.D
ABSOLUTE MAXIMUM RATINGS (TA=25°C, unless otherwise specified)
PARAMETER
SYMBOL
RATINGS
UNIT
Peak Repetitive Reverse Voltage
VRRM
40
V
Working Peak Reverse Voltage
VRWM
V
DC Blocking Voltage
VR
V
RMS Reverse Voltage
VR(RMS)
28
V
Operating Temperature
TJ
+125
°C
Storage Temperature
TSTG
-65~+150
°C
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
THERMAL DATA
PARAMETER
SYMBOL
RATINGS
UNIT
Junction to Ambient (Note 1)
θJA
75
°C/W
Note: 1. Mounted on P.C. Board with 5.0mm
2 copper pad area.
ELECTRICAL CHARACTERISTICS (TA=25°C, unless otherwise specified)
PARAMETER
SYMBOL
RATINGS
UNIT
Average Rectified Output Current (TL=75°C)
IO
2.0
A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed On Rated Load
(JEDEC Method)
IFSM
50
A
Forward Voltage (IF=2.0A)
VFM
0.50
V
Peak Reverse Current At Rated DC
Blocking Voltage
TA=25°C
IRM
0.5
mA
TA=100°C
20
mA
