74ACT715S-RSC datasheet(5/18 Pages) FAIRCHILD

5 / 18 page

www.fairchildsemi.com

74ACT715, 74ACT715-R Rev. 1.3

All of the data registers are 12 bits wide. Width’s of all

pulses are defined by specifying the start count and end

count of all pulses. Horizontal pulses are specified with

respect to the number of clock pulses per line and verti-

cal pulses are specified with respect to the number of

lines per frame.

REG0—Status Register

The Status Register controls the mode of operation, the

signals that are output and the polarity of these outputs.

The default value for the Status Register is 0 (000 Hex) for

the ACT715 and is “1024” (400 Hex) for the ACT715-R.

Bits 0–2

Bits 3–4

Double Equalization and Serration mode will output

equalization and serration pulses at twice the HSYNC

frequency (i.e., 2 equalization or serration pulses for

every HSYNC pulse). Single Equalization and Serration

mode will output an equalization or serration pulse for

every HSYNC pulse. In Interlaced mode equalization

and serration pulses will be output during the VBLANK

period of every odd and even field. Interlaced Single

Equalization and Serration mode is not possible with this

part.

Bits 5–8

Bits 5 through 8 control the polarity of the outputs. A

value of zero in these bit locations indicates an output

pulse active LOW. A value of 1 indicates an active HIGH

pulse.

B5—

VCBLANK Polarity

B6—

VCSYNC Polarity

B7—

HBLHDR Polarity

B8—

HSYNVDR Polarity

Bits 9–11

Bits 9 through 11 enable several different features of the

device.

B9—

Enable Equalization/Serration Pulses (0)

Disable Equalization/Serration Pulses (1)

B10—

Disable System Clock (0)

Enable System Clock (1)

Default values for B10 are “0” in the ACT715

and “1” in the ACT715-R.

B11—

Disable Counter Test Mode (0)

Enable Counter Test Mode (1)

This bit is not intended for the user but is for

internal testing only.

Horizontal Interval Registers

The Horizontal Interval Registers determine the number

of clock cycles per line and the characteristics of the

Horizontal Sync and Blank pulses.

REG1— Horizontal Front Porch

REG2— Horizontal Sync Pulse End Time

REG3— Horizontal Blanking Width

REG4— Horizontal Interval Width # of Clocks per Line

Vertical Interval Registers

The Vertical Interval Registers determine the number of

lines per frame, and the characteristics of the Vertical

Blank and Sync Pulses.

REG5— Vertical Front Porch

REG6— Vertical Sync Pulse End Time

REG7— Vertical Blanking Width

REG8— Vertical Interval Width # of Lines per Frame

Equalization and Serration Pulse Speciﬁcation

Registers

These registers determine the width of equalization and

serration pulses and the vertical interval over which they

occur.

REG 9— Equalization Pulse Width End Time

REG10— Serration Pulse Width End Time

REG11— Equalization/Serration Pulse Vertical Interval

Start Time

REG12— Equalization/Serration Pulse Vertical Interval

End Time

Vertical Interrupt Speciﬁcation Registers

These Registers determine the width of the Vertical

Interrupt signal if used.

REG13— Vertical Interrupt Activate Time

REG14— Vertical Interrupt Deactivate Time

B2 B1 B0 VCBLANK VCSYNC HBLHDR HSYNVDR

CBLANK

CSYNC

HGATE

VGATE

(DEFAULT)

VBLANK

CSYNC

HBLANK

VGATE

CBLANK

VSYNC

HGATE

HSYNC

VBLANK

VSYNC

HBLANK

HSYNC

CBLANK

CSYNC

CUSOR

VINT

VBLANK

CSYNC

HBLANK

VINT

CBLANK

VSYNC

CUSOR

HSYNC

VBLANK

VSYNC

HBLANK

HSYNC

Mode of Operation

Interlaced Double Serration and Equalization

(DEFAULT)

Non Interlaced Double Serration

Illegal State

Non Interlaced Single Serration and Equalization
