Part numbering

M24M01-R, M24M01-W, M24M01-HR

32/37

Doc ID 12943 Rev 7

Part numbering

Table 19.

Ordering information scheme (M24M01-x products sold in packages)

Example:

M24M01

–

H R MN

Device type

M24 = I2C serial access EEPROM

Device function

M01 = 1 Mbit (256 Kb × 8 bits)

Clock frequency

Blank: fC max = 400 kHz

H: fC max = 1 MHz

Operating voltage

W = VCC = 2.5 V to 5.5 V

R = VCC = 1.8 V to 5.5 V

Package

MN = SO8 (150 mils width)

MW = SO8 (208 mils width)

CS = WLCSP

Device grade

6 = Industrial temperature range, –40 to 85 °C.

Device tested with standard test flow

3 = Automotive: device tested with high reliability certified flow(1) over –40 to 125 °C

ST strongly recommends the use of automotive grade devices for use in automotive environments. The

high reliability certified flow (HRCF) is described in the quality note QNEE9801. Please ask your nearest

ST sales office for a copy.

Option

blank = standard packing

T = tape and reel packing

Plating technology

P or G = ECOPACK® (RoHS compliant)

Process(2)

The Process letter only concerns grade 3 devices and WLCSP devices.

A = F8L
