background image
Low-Power, Multifunction, Polyphase AFE
with Harmonics and Tamper Detect
______________________________________________________________________________________
99
Fundamental Apparent Energy, Phase A/B/C/T (ENRSF.X)
(A: 0x8B1, B: 0x8B2, C: 0x8B4, T: 0x8B7)
This register contains the apparent accumulated energy delivered into phase A/B/C or total. The register is the prod-
uct of the ENR_CC and X.ESF registers.
Current Total Harmonic Distortion Plus Noise, Phase A/B/C (THDN.X)
(A: 0x859, B:0x85A, C: 0x85C)
This signed register contains for a phase current the total harmonic distortion plus noise (power) ratio, computed as
below, where X.IRMSFUND is the fundamental current RMS.
Note that the sign bit is at the most significant bit of byte 5.
THDN X
XIRMS
XIRMS
FUND
.
.
.
=−
2
2
1
Byte 7 (MSByte unused)
Byte 6 (unused)
Byte 5
Byte 4
Byte 3
Byte 2
Byte 1
Byte 0 (LSByte)
Byte 7 (MSByte unused)
Byte 6 (unused)
Byte 5
Byte 4
Byte 3
Byte 2
Byte 1
Byte 0
