3 / 16 page  AD8120 Rev. 0 | Page 3 of 16 SPECIFICATIONS TA = 25°C, VS = ±5 V, RL = 150 Ω, 10% to 90% input rise/fall time (tR/tF) = 4 ns, unless otherwise noted. Table 1. Parameter Test Conditions/Comments Min Typ Max Unit DELAY CHARACTERISTICS Total Adjustable Delay Range Delay Code 63 to Delay Code 0 50 ns Delay Resolution Monotonic, 1 LSB 0.8 ns Propagation Delay Delay = 0 ns 4.9 ns Channel-to-Channel Delay Error All channels at maximum delay 0.4 ns DYNAMIC PERFORMANCE −3 dB Video Signal Bandwidth VOUT = 1.4 V p-p, delay = 0 ns 200 MHz VOUT = 1.4 V p-p, delay = 50 ns 150 MHz −3 dB Small-Signal Bandwidth VOUT = 0.2 V p-p, delay = 0 ns 165 MHz VOUT = 0.2 V p-p, delay = 50 ns 140 MHz 0.1 dB Video Signal Flatness VOUT = 1.4 V p-p, delay = 0 ns 27 MHz VOUT = 1.4 V p-p, delay = 50 ns 35 MHz 10% to 90% Rise/Fall Time VOUT = 1.4 V step, delay = 0 ns 2.5/3 ns VOUT = 1.4 V step, delay = 50 ns 3/4.2 ns Settling Time to 1% VOUT = 1.4 V step, delay = 0 ns 8 ns VOUT = 1.4 V step, delay = 50 ns 18 ns Slew Rate VOUT = 1.4 V step, delay = 0 ns, rising edge 550 V/μs VOUT = 1.4 V step, delay = 0 ns, falling edge 540 V/μs VOUT = 1.4 V step, delay = 50 ns, rising edge 510 V/μs VOUT = 1.4 V step, delay = 50 ns, falling edge 360 V/μs Overshoot VOUT = 1.4 V step, delay = 0 ns 1 % VOUT = 1.4 V step, delay = 50 ns 20 % Gain 0 ns to 50 ns delay 1.95 2.01 2.06 V/V Channel-to-Channel Gain Matching Over all codes, among all channels 0.8 3 % Hostile Crosstalk Measured on G with R and B driven at 1 MHz, VOUT = 1.4 V p-p, delay = 0 ns −80 dB VIDEO INPUT CHARACTERISTICS RIN, GIN, BIN Input Bias Current 0.8 1.5 μA Input Capacitance 1 pF Input Resistance 500 kΩ VIDEO OUTPUT CHARACTERISTICS ROUT, GOUT, BOUT Output Voltage Swing ±3.25 V Output Current 50 mA Integrated Output Noise 100 kHz to 160 MHz Delay = 0 ns 1 mV rms Delay = 50 ns 4 mV rms Output Offset Voltage (RTI) Over all codes −30 0 +30 mV Channel-to-Channel Output Offset Voltage Matching (RTI) Over all codes, among all channels 30 mV Output Impedance PD high, at 20 MHz 1.5 Ω ANALOG CONTROL INPUT CHARACTERISTICS Input Bias Current VCR, VCG, VCB 1 μA Operating Range VCR, VCG, VCB 0 2 V Delay Voltage Step Size in Linear Range ΔVCR, ΔVCG, ΔVCB to move one delay LSB 28 mV |
|
|
