Elektronische Bauelemente

SCS4

448WS

Surface Mount Fast Switching Diode

ELECTRICAL CHARACTERISTICS (Ta=25

)

TYPE NUMBER

SYMBOL

Min.

Max.

UNITS

Test Condition

Reverse Breakdown Voltage

VRM

IR = 1.0µA

0.7

IF =

5.0mA

0.855

IF = 10mA

1.0

IF =

100mA

Forward Voltage (Note 2)

VFM

1.25

IF = 150mA

2.5

µA

VR = 75V, TJ =

VR = 25V, TJ =

Peak Reverse Current (Note 2)

IRM

Total Capacitance

4.0

VR = 0, f = 1.0MHz

IF = IR = 10mA,

Reverse Recovery Time

trr

4.0

Irr = 0.1x IR, RL = 100

NOTES:

1. Part mounted on FR-4 PC board with recommended pad layout,

2. Short duration test pulse used to minimize self-heating effect.

RATING AND CHARACTERISTIC CURVES

http://www.SeCoSGmbH.com/

Any changing of specification will not be informed individual

01-Jun-2002 Rev. A

Page 2 of 2
