background image
Elektronische Bauelemente
SCS4148WS
Surface Mount Fast Switching Diode
ELECTRICAL CHARACTERISTICS (Ta=25
)
TYPE NUMBER
SYMBOL
Min.
Max.
UNITS
Test Condition
Reverse Breakdown Voltage
VRM
75
-
V
IR = 1.0µA
0.715
IF = 1.0mA
0.855
IF = 10mA
1.0
IF = 50mA
Forward Voltage (Note 2)
VFM
-
1.25
V
IF = 150mA
1.0
µA
VR = 75V
50
µA
VR = 75V, TJ = 150
30
µA
VR = 25V, TJ = 150
Peak Reverse Current (Note 2)
IRM
-
25
nA
VR = 20V
Total Capacitance
CT
-
2.0
pF
VR = 0, f = 1.0MHz
IF = IR = 10mA,
Reverse Recovery Time
trr
-
4.0
ns
Irr = 0.1x IR, RL = 100
NOTES:
1. Part mounted on FR-4 PC board with recommended pad layout,
2. Short duration test pulse used to minimize self-heating effect.
RATING AND CHARACTERISTIC CURVES
http://www.SeCoSGmbH.com/
Any changing of specification will not be informed individual
0
100
0
25
50
75
125
100
150
T , AMBIENT TEMPERATURE (°C)
A
Fig. 1 Power Derating Curve
300
200
10
1.0
100
1000
0.1
0.01
0
1
2
V , INSTANTANEOUS FORWARD VOLTAGE (V)
F
Fig. 2 Forward Characteristics
1
10
100
1000
10,000
0
100
200
T , JUNCTION TEMPERATURE (°C)
j
Fig. 3 Leakage Current vs Junction Temperature
V = 20V
R
01-Jun-2002 Rev. A
Page 2 of 2
