Section 9 Bus Controller (BSC)
Rev. 2.00 Sep. 24, 2008 Page 345 of 1468
REJ09B0412-0200
A refresh cycle is not executed during a consecutive cluster transfer even if a refresh request is
generated. Therefore, user program must control the time so that each bank should not be activated
over a given specification. The external bus is not released during a cluster transfer.
T
p
T
r
T
cb
T
c2
T
cb
T
cb
T
cb
T
cb
T
c1
T
cl
PALL ACTV
READ
NOP
Address bus
Row
Cloumn 1 Cloumn 2 Cloumn 3 Cloumn 4 Cloumn 5
Cloumn 6
SDRAM
φ
CS
Precharge-sel
RAS
CAS
WE
CKE
DQMUU
DQMUL
D31 to D24
D23 to D16
DQMLU
DQMLL
D7 to D0
BS
RD/
WR
D15 to D8
Row
High
Figure 9.91 Word-Size 6-Word Cluster Transfer
(Read, BE = 1, EDDS = 1, CAS Latency = 2)
