STV2001
18/46
Figure 1. EW Output Referred Voltage
Figure 2. Dynamic Horizontal Phase Control Output
Figure 3. Keystone Effect on EW Output (PCC Inhibited)
Figure 4. Vertical Dynamic FOcus Output
A
EWDC
EWPARA
B
DHPCDC
EWPARA
SPBPARA
A
B
Keyadj
4Vdc
