MECHANICAL DATA
Issue 1.0 - July 24, 2002
69/111
5. MECHANICAL DATA
5.1. 516-PIN PACKAGE DIMENSION
The pin numbering for the STPC 516-pin Plastic
BGA package is shown in Figure 5-1.
Dimensions are shown in Figure 5-2, Table 5-1
and Figure 5-3, Table 5-2.
Figure 5-1. 516-Pin PBGA Package - Top View
