ST3237ECPR Datasheet(PDF) 2 Page - STMicroelectronics |
|
|
|||||||||||||||||||||||||||||
ST3237ECPR Datasheet(HTML) 2 Page - STMicroelectronics |
|
|
2 / 15 page  ST3237E 2/15 Table 2: Pin Description PlN N° SYMBOL NAME AND FUNCTION 1 C2+ Positive Terminal of Inverting Charge Pump Capacitor 2 GND Ground 3 C2- Negative Terminal of Inverting Charge Pump Capacitor 4 V- -5.5V Generated by the Charge Pump 5 T1OUT First Transmitter Output Voltage 6 T2OUT Second Transmitter Output Voltage 7 T3OUT Third Transmitter Output Voltage 8 R1IN First Receiver Input Voltage 9 R2IN Second Receiver Input Voltage 10 T4OUT Fourth Transmitter Output Voltage 11 R3IN Third Receiver Input Voltage 12 T5OUT Fifth Transmitter Output Voltage 13 EN Receiver Enable, Active Low 14 SHDN Shutdown Control, Active Low 15 VHSCI Very High Speed Control Input. Connected to GND for normal operation; connected to VCC for 1Mbps transmission rates. 16 R1OUTB Non Inverting Complementary Receiver Output. Always Active. 17 T5IN Fifth Transmitter Input Voltage 18 R3OUT Third Receiver Output Voltage 19 T4IN Fourth Transmitter Input Voltage 20 R2OUT Second Receiver Output Voltage 21 R1OUT First Receiver Output Voltage 22 T3IN Third Transmitter Input Voltage 23 T2IN Second Transmitter Input Voltage 24 T1N First Transmitter Input Voltage 25 C1- Negative Terminal of Voltage-Doubler Charge Pump Capacitor 26 VCC Supply Voltage 27 V+ 5.5V Generated by the Charge Pump 28 C1+ Positive Terminal of Voltage-Doubler Charge Pump Capacitor |
|
|
