4

Technical Drawing with cables (mm) 3D Drawing

3D drawing files are available on request from ILS. Please call or email

1 OSLON Square PowerStar Lens and Reflector Options

LEDiL precision-engineered Lenses and Reflectors allow for rapid deployment of all types of light fixtures,

including street lights, wall-wash, high-bay, sconces, emergency beacons, parking garage/low-bay, MR and

AR down lights, and dock lights. Precision-engineered for maximum efficiency and durability, LEDiL Lenses

and Reflectors are released alongside the latest product releases from our LED suppliers. You select the best

LED for the application; choose LEDiL and you’re selecting the best optical solution as well.

Ordering Code

Beam

Diameter

Height Family

FWHM Material/Lens Colour Fastening

C13155_EMERALD-A

O

21.6

6.9

Emerald

0

PMMA

clear

glue, pin

CA13156_EMERALD-A

O

21.6

7.3

Emerald

152+76 PMMA

clear

tape, pin

CA11388_EMILY-M

M

26

14.85

Emily

0

PMMA

clear

tape, pin

CA11389_EMILY-O

O

26

14.97

Emily

0

PMMA

clear

tape, pin

CA11391_EMILY-M2

M2

26

14.88

Emily

0

PMMA

clear

tape, pin

CA12062_EMILY-D

D

26

14.74

Emily

0

PMMA

clear

tape, pin

CA13546_EMILY-RS

RS

26

14.74

Emily

0

PMMA

clear

tape

CA15359_EMILY-WW

WW

26

14.74

Emily

44

PMMA

clear

pin, tape

FCA15451_FLORENTINA-1-M

39.7x39.7

17.55

Florentina

31

PC

black

FCA15452_FLORENTINA-1-O

O

39.7x39.7

17.552

Florentina

44+17

PC

black
