2003 Series Gas Discharge Tube Surge Protector

Product Dimensions

How to Order

2003 - xx - SM - RP LF

Model Number Designator

Voltage (Divided by 10)

Surface Mount

Packaging

RP = Reelpack

RoHS Compliancy

LF = RoHS Compliant Product

Recommended Pad Layout

DIMENSIONS: MILLIMETERS

REV. A 10/17

3.5 ± 0.2

3.5 ± 0.2

2.8 ± 0.2

2.8 ± 0.2

2.1 ± 0.2

0.5

2.8 ± 0.2

2.8 ± 0.2

2.8 ± 0.2

2.5

1.2

4.0

3.5 ± 0.2

3.5 ± 0.2

2.8 ± 0.2

2.8 ± 0.2

2.1 ± 0.2

0.5

2.8 ± 0.2

2.8 ± 0.2

2.8 ± 0.2

2.5

1.2

4.0

DIMENSIONS: MILLIMETERS

Typical Part Marking

2003-07-SM-RPLF ................................................................. B07

2003-09-SM-RPLF ................................................................. B09

2003-12-SM-RPLF ................................................................. B12

2003-15-SM-RPLF ................................................................. B15

2003-20-SM-RPLF ................................................................. B20

2003-23-SM-RPLF ................................................................. B23

2003-25-SM-RPLF ................................................................. B25

2003-35-SM-RPLF ................................................................. B35

2003-40-SM-RPLF ................................................................. B40

2003-47-SM-RPLF ................................................................. B47

3.5 ± 0.2

3.5 ± 0.2

2.8 ± 0.2

2.8 ± 0.2

2.1 ± 0.2

0.5

2.8 ± 0.2

2.8 ± 0.2

2.8 ± 0.2

2.5

1.2

4.0

Packaging Specifications

The Model 2003-xx-SM ships standard reelpack (-RP), 2,500 pieces per reel,

7,500 pieces per box. Reel is 330 mm in diameter and 12 mm wide.

DIMENSIONS: MILLIMETERS

1.5 +0.1/-0

DIA.

4.0 ± 0.1

2.0 ± 0.1

0.4 ± 0.1

8.0 ± 0.1

12.0 ± 0.3

1.75 ± 0.1

5.5 ± 0.1

3.9 ± 0.1

3.2 ± 0.1

3.2 ± 0.1

330 ± 4.0

DIA.

1.5

MIN.

100

TYP.

1.5 +0.1/-0

DIA.

4.0 ± 0.1

2.0 ± 0.1

0.4 ± 0.1

8.0 ± 0.1

12.0 ± 0.3

1.75 ± 0.1

5.5 ± 0.1

3.9 ± 0.1

3.2 ± 0.1

3.2 ± 0.1

330 ± 4.0

DIA.

1.5

MIN.

100

TYP.
