 3 / 27 page
background image
General Information
Items
Specification
Unit
Note
Main Panel
Display area(AA)
26.64(H)*35.52(V) (1.77inch)
mm
-
Driver element
TFT active matrix
-
-
Display colors
65/262K
colors
-
Number of pixels
240(RGB)*320
dots
-
Pixel arrangement
RGB vertical stripe
-
-
Pixel pitch
0.111(H)*0.111(V)
mm
-
Viewing angle
Free
o'clock
-
Controller
IC
ST7789S
-
-
Display mode
Transmissive/Normally black
-
-
Operating temperature
-20～+70
℃
-
Storage temperature
-30～+80
℃
-
* Mechanical Information
Item
Min.
Typ.
Max.
Unit
Note
Module
size
Horizontal(H)
34.7
mm
-
Vertical(V)
46.7
mm
-
Depth(D)
2.65
mm
-
Weight
TBD
g
-
1. Block Diagram
Page 3 of 27
