3.0 USB Cable

USB A Male to Male

Specifications:

Connector Type A

: USB 3.0 A Plug

Connector Type B

: USB 3.0 A Plug

Jacket Colour:

: Blue

Cable Length - Imperial

: 3.28ft

Cable Length - Metric

: 1m

Electrical Test:

100% Open & short & Mis wire Test

Insulation Resistance

: 10MΩ (Min.)

Contact Resistance

: 2Ω (Max.)

Hi-Pot Test

: DC 100V/10ms

Important Notice : This data sheet and its contents (the “Information”) belong to the members of the Premier Farnell group of companies (the “Group”) or are licensed to it. No licence is granted

for the use of it other than for information purposes in connection with the products to which it relates. No licence of any intellectual property rights is granted. The Information is subject to change

without notice and replaces all data sheets previously supplied. The Information supplied is believed to be accurate but the Group assumes no responsibility for its accuracy or completeness, any

error in or omission from it or for any use made of it. Users of this data sheet should check for themselves the Information and the suitability of the products for their purpose and not make any

assumptions based on information included or omitted. Liability for loss or damage resulting from any reliance on the Information or use of it (including liability resulting from negligence or where the

Group was aware of the possibility of such loss or damage arising) is excluded. This will not operate to limit or restrict the Group’s liability for death or personal injury resulting from its negligence.

pro-SIGNAL is the registered trademark of the Group. © Premier Farnell plc 2012.

Part Number Table

Description

Part Number

3.0 USB Cable

USB A Male to Male

RP021

Dimensions : Millimetres

No.

Item

Description

Qty Unit

1

A4-R002034

(28AWG × 1P + D + AL + MYLAR) × 2C +

(28AWG × 1P + AL) + 28AWG × 2C + AEB

65%AL OD:5.5 ±0.2mm Colour : Blue

L

m

2

A2-R028316 USB 3.0 A (Male) 9P Solder Insulation Blue

2

Pcs

3

A6-R028171 USB 3.0 A (Male) Front Shell Plated Nickel

2

Pcs

4

A6-R028172 USB 3.0 A (Male) Back Shell Plated Nickel

2

Pcs

5

A5-R047095

45P Blue PVC

-

g
