KW CSLPM2.PC

DATASHEET

2 | Version 1.7 | 2023-01-04

OSLON® Square Flat

KW CSLPM2.PC

The most compact 3 x 3 mm high power LED with an electrical-

ly isolated thermal pad allows for superior heat dissipation de-

signs. The flat package shape enhances color homogeneity due

to reduced color over angle variation. Extremely low thermal

resistance helps to maintain the efficiency remarkably high even

when driven at higher currents.

Applications

- Entertainment

- Transportation

Features

- Package: Ceramic package

- Chip technology: UX:3

- Typ. Radiation: 120° (Lambertian emitter)

- Color: Cx = 0.32, Cy = 0.33 acc. to CIE 1931 (● white)

- Corrosion Robustness Class: 2B

- Color temperature: 5000K - 6500K

- CRI: 70 (typ.)

- ESD: 8 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 3B)
