2 / 4 page

[2.Model Number Configuration]

■

Rated Voltage

■

Installation • Wiring

■

LED Unit Color

12-24V DC

J : 3-screw Mounting･Cabtyre Cord

R : Red

100-240V AC

2-point Hole Type Mounting･Terminal Block

Y : Amber

G : Green

B : Blue

[mm]

Applicable Wire Size Solid Wire : 0.13-1.5mm2 ,

Stranded Wire : AWG28-14

Material ・ Specification

- M

N -

Terminal Block

[3.Outer Dimensions]

Waterproof Sheet

Silicone

Mounting Bracket

Globe

LCP GF,

Drawing No.

Rev.

Page

SL15-M1JN-

W18

S L 1

Number

Name

UL2464, PVC, M1JN : AWG22×5, M2JN : AWG18×2+AWG24×3

Cabtyre Cord

Case

■

SL15-M1JN/SL15-M2JN

■

SL15-M1KTN/SL15-M2KTN

・

Maximum Board Thickness：10

Plain Washer(M8)

Nut(M8)

SUS

3 pcs.

Accessory(Only SL15-M□JN）

Screw Hole Thickness

of Mounting Bracket

Nominal

Diameter

4.8

150

From the cord outlet 500±30

3-M8

(SUS)

Nameplate

7.7

2/4
