[1.General Specifications]

Conforms to the CE Requirements

SL15-M2JN

Blinking (180 flashes per minute), Triple-flash(120 flashes per minute)

Flashing Rate (Typ.)

EN61000-6-4, EN61000-6-2

EN61000-3-2, EN61000-3-3

EMC Directive

EN61000-6-2

RoHS Directive

KC

and non-current carrying metallic part

without breaking insulation

Environmental Condition

Insulation Resistance

and non-current carrying metallic part

and non-current carrying metallic part

and non-current carrying metallic part

500V AC applied for 1min between live part

SL15-M2KTN

SL15-M□JN

Storage Ambient Humidity

SL15-M□KTN

Mounting Direction

Less than 90 % (No condensation)

Indoor : Upright, Inverted & Sideways

Max.

Mounting Location

-30℃ to +60℃

240V AC

0.06A

Upright

Rated Power

Consumption

Storage Ambient Temperature

Operating Voltage Range

10-30V DC

100V AC

0.14A

12V DC

24V DC

0.40A

0.20A

90-250V AC

Rated Current

Consumption

12-24V DC

Outdoor : Upright

-20℃ to +50℃

Less than 90 % (No condensation)

0.89kg

SL15-M1KTN

0.86kg

0.89kg

Model

SPECIFICATIONS

Rated Voltage

SL15-M2□□N-□

SL15-M1□□N-□

100-240V AC (50/60Hz)

Product Name

Flashing Beacons

Drawing No.

Rev.

SL15-M1JN-

W18

G

Page

Withstand Voltage

EN IEC 63000

FCC Part15 SubpartB ClassA, ICES-003 ClassA

Mass (Typ.)

IP66/NEMA TYPE 4X,13

EN61000-6-4

FCC

4,000V AC applied for 1min between live part

without breaking insulation

Protection Rating

KN61000-6-4, KN61000-6-2

0.86kg

UL and Low Voltage Directive have been evaluated for use

SL15-M1JN

in indoor industrial control equipment.

Due to the characteristics of the LED elements, there may be a slight variation in color

tone and brightness between products.

UL508, CSA-C22.2 No.14 (UL File No.E215660)

Max.

5.6W

4.8W

More than 1MΩ at 500V DC between live part More than 3MΩ at 500V DC between live part

IP23

Operating Ambient Temperature

Operating Ambient Humidity

Indoor/Outdoor

Conforms to the UKCA Requirements

Conformity

Standards

Low Voltage

Directive

IEC/EN60947-5-1,EN62471

UL

Remarks

1/4
