1 / 40 page

January 2008

Rev 5

1/40

1

M95M01-R

1 Mbit serial SPI bus EEPROM

with high speed clock

Features

■ Compatible with SPI bus serial interface

(Positive Clock SPI modes)

■ Schmitt trigger inputs for enhanced noise

margin

■ Single supply voltage: 1.8 V to 5.5 V

■ High speed

– 5 MHz clock rate

– 5 ms Write time

■ Status Register

■ Hardware Protection of the Status Register

■ Byte and Page Write (up to 256 bytes)

■ Self-timed programming cycle

■ Adjustable size read-only EEPROM area

■ Enhanced ESD Protection

■ More than 1 000 000 Write cycles

■ More than 40-year data retention

■ Packages

– ECOPACK® (RoHS compliant)

SO8N (MN)

150 mils width

SO8W (MW)

208 mils width

www.st.com
