A-24

71.5

(2.81)

35.8

(1.41)

90.0

(3.54)

102.0

(4.02)

110.0

(4.33)

50.0

(1.97)

10.8

(0.42)

(M4) 3.9 DIA.

(0.157)

58.0

(2.28)

45.0

(1.77)

4.5

(0.18)

56.5

(2.22)

47.5

(1.87)

EZ500

107.5

(4.23)

90.0

(3.54)

102.0

(4.02)

110.0

(4.33)

75.0

(2.96)

16.3

(0.64)

(M4) 3.9 DIA.

(0.157)

58.0

(2.28)

45.0

(1.77)

4.5

(0.18)

56.5

(2.22)

47.5

(1.87)

16.3

(0.64)

EZ700

Dimensions: mm (inch)

107.5

(4.23)

90.0

(3.54)

102.0

(4.02)

110.0

(4.33)

75.0

(2.96)

16.3

(0.64)

(M4) 3.9 DIA.

(0.157)

72.0

(2.83)

45.0

(1.77)

4.5

(0.18)

70.5

(2.78)

48.5

(1.91)

16.3

(0.64)

EZ800

MODEl nO.

EZ512-AC

EZ512-DC-R

EZ719-AC EZ719-DC-RC EZ819-AC

EZ819-DC-RC

supplY VOltAGE

100 to

100 to

100 to

240 Vac

24 Vdc

240 Vac

24 Vdc

240 Vac

24 Vdc

HEAt DIssIpAtIOn

5 VA

2 W

10 VA

3.5 W

10 VA

3.4 W

COntInuOus CuRREnt

Outputs (1)

8 A

8 A

8 A

8 A

8 A

8 A

MOuntInG

On top-hat rail to DIN 50022, 35 mm or screw mounting with

EZB4-101-GF1 fixing brackets

COnnECtIOn CABlEs

0.2 to 4.0 mm2 (AWG 22-12), solid 0.2 to 2.5 mm2 (AWG 22-12), flexible

DEGREE Of pROtECtIOns

IP 20

RfI suppREssIOn

EN 55011, EN 55022 Class B, IEC 61000-6-1, 2, 3, 4

AMBIEnt OpERAtInG

tEMpERAtuRE

-25 to 55°C

tRAnspORt AnD stORAGE

tEMpERAtuRE

-40 to 70°C

CERtIfICAtIOn,

stAnDARDs

EN 50178, IEC/EN 60947, UL, CSA, Class 1, Div 2

EZ500, EZ700 and EZ800 Series

88.1

(3.47)

90.0

(3.54)

19.0

(0.75)

25.0

(0.98)

EZD-R

(M4) 3.9 DIA.

(0.157)

7.5

(0.30)

110.0

(4.33)

102.0

(4.02)

90.0

(3.54)

7.5

(0.30)

35.5

(1.40)

47.5

(1.87)

56.5

(2.22)

4.5

(0.18)

45.0

(1.77)

58.0

(2.28)

EZ202-RE

EZ200-EZ

EZ205-ASI
