Package information

In order to meet environmental requirements, ST offers these devices in different grades of ECOPACK®

packages, depending on their level of environmental compliance. ECOPACK® specifications, grade definitions

and product status are available at: www.st.com. ECOPACK® is an ST trademark.

2.1

Isotop package information

•

Epoxy meets UL94, V0

•

Cooling method: by conduction (C)

•

Recommended torque value: 1.3 N·m

•

Maximum torque value: 1.5 N·m

STMicroelectronics strongly recommend the use of the screws delivered with this product.

The use of any other screws is entirely at the user's own risk and will invalidate the warranty.

Figure 10. ISOTOP package outline

G1

F1

S

D

P1

B

Ø P

E1

G D1

F

E

G2

A

C

A1

E2

M4 NUTS (×4)

C2

Gate

note 4

c

H

STTH20003
