Antenna
¼ Wave Whip Antenna Dimensions (mm)
M4
4BA
BNC
BNC 90°
Length
Dia
Length
Dia
Dia
Length
Dia
Length
315MHz
*
*
231
18
13
250
433MHz
162.5
13
160.5
17
13
172
*
*
458MHz
-
-
-
16
-
164
868MHz
97
13
-
17.5
-
81
916MHz
-
-
83
-
13
-
Helical / Compressed Helical / Gain Antenna Dimensions (mm)
Helical M4
Helical 4BA
Helical BNC
Comp. Helical
M4
Gain
Length
Dia
Length
Dia
Length
Dia
Length
Dia
Length
Dia
173MHz
-
-
*
*
-
-
-
-
*
*
315MHz
-
-
72
13
105
17
-
-
*
*
433MHz
55
14
55.5
13
84
17
35
14
490
14
458MHz
-
-
-
-
81
17
-
-
-
-
868MHz
-
-
-
-
-
-
-
-
-
-
916MHz
-
-
83
13
*
*
-
-
-
-
Puk / Dipole Antenna Dimensions (mm)
Puk
Dipole
Height
Dia
Cable Length
Length
Width
Height
Cable Length
433MHz
52
47
500
900/1800 MHz
112
60
10
175
GPS Antenna Dimensions (mm)
GPS - SMA / HFL
GPS - MMCX
Height
Dia
Cable Length
Height
Dia
Cable Length
1575 MHz
10
56
5000
14.5
49
5000
