background image
Data Sheet
ADBMS1818
THEORY OF OPERATION
analog.com
Rev. B | 42 of 92
Table 38. Write Codes for ICOMn, Bits[3:0] and FCOMn, Bits[3:0] on SPI Master
Control Bits
Code
Action
Description
ICOMn, Bits[3:0]
1000
CSBM low
Generates a CSBM low signal on SPI port (GPIO3)
1010
CSBM falling edge
Drives CSBM (GPIO3) high, then low
1001
CSBM high
Generates a CSBM high signal on SPI port (GPIO3)
1111
No transmit
Releases the SPI port and ignores the rest of the data
FCOMn, Bits[3:0]
X000
CSBM low
Holds CSBM low at the end of byte transmission
1001
CSBM high
Transitions CSBM high at the end of byte transmission
