4 / 25 page  Data Sheet ADL5513 SPECIFICATIONS analog.com Rev. B | 4 of 25 Table 1. (Continued) Parameter Test Conditions/Comments Min Typ Max Unit −40°C < TA < +25°C; PIN = −50 dBm +0.37/−0.5 dB 25°C < TA < 125°C; PIN = −50 dBm +0.67/−0.28 dB Logarithmic Slope 21 mV/dB Logarithmic Intercept −88 dBm Input Impedance 1.3/0.4 kΩ/pF FREQUENCY = 1900 MHz Output Voltage: High Power Input PIN = −10 dBm 1.66 V Output Voltage: Low Power Input PIN = −50 dBm 0.80 V ±3.0 dB Dynamic Range 75 dB ±1.0 dB Dynamic Range 70 dB ±0.5 dB Dynamic Range 68 dB Maximum Input Level, ±1.0 dB 8 dBm Minimum Input Level, ±1.0 dB −62 dBm Deviation at TA = 25°C PIN = −10 dBm 0.25 dB PIN = −30 dBm 0.0012 dB PIN = −50 dBm 0.52 dB Deviation vs. Temperature Deviation from output at TA = 25°C 25°C < TA < 85°C; PIN = −10 dBm +0.14/−0.41 dB −40°C < TA < +25°C; PIN = −10 dBm +0.19/−0.51 dB 25°C < TA < 125°C; PIN = −10 dBm 0.9 dB 25°C < TA < 85°C; PIN = −30 dBm +0.1/−0.38 dB −40°C < TA < +25°C; PIN = −30 dBm +0.37/−0.26 dB 25°C < TA < 125°C; PIN = −30 dBm 0.83 dB 25°C < TA < 85°C; PIN = −50 dBm +0.55/−0.3 dB −40°C < TA < +25°C; PIN = −50 dBm +0.79/−0.16 dB 25°C < TA < 125°C; PIN = −50 dBm +0.62/−0.41 dB Logarithmic Slope 21 mV/dB Logarithmic Intercept −88 dBm Input Impedance 0.6/0.5 kΩ/pF FREQUENCY = 2140 MHz Output Voltage: High Power Input PIN = −10 dBm 1.66 V Output Voltage: Low Power Input PIN = −50 dBm 0.82 V ±3.0 dB Dynamic Range 77 dB ±1.0 dB Dynamic Range 70 dB ±0.5 dB Dynamic Range 66 dB Maximum Input Level, ±1.0 dB 8 dBm Minimum Input Level, ±1.0 dB −62 dBm Deviation at TA = 25°C PIN = −10 dBm 0.33 dB PIN = −30 dBm 0.02 dB PIN = −50 dBm 0.23 dB Deviation vs. Temperature Deviation from output at TA = 25°C 25°C < TA < 85°C; PIN = −10 dBm ±0.28 dB −40°C < TA < +25°C; PIN = −10 dBm +0.2/−0.52 dB 25°C < TA < 125°C; PIN = −10 dBm +0.7/−0.1 dB 25°C < TA < 85°C; PIN = −30 dBm +0.15/−0.35 dB −40°C < TA < +25°C; PIN = −30 dBm +0.24/−0.41 dB 25°C < TA < 125°C; PIN = −30 dBm 0.77 dB 25°C < TA < 85°C; PIN = −50 dBm +0.2/−0.6 dB |
|
|
