AD8310

Rev. F | Page 13 of 24

For zero-signal conditions, all the detector output currents are

equal. For a finite input of either polarity, their difference is

converted by the output interface to a single-sided unipolar

current, nominally scaled 2 μA/dB (40 μA/decade), at the

output pin BFIN. An on-chip resistor of ~3 kΩ, R1, converts

this current to a voltage of 6 mV/dB. This is then amplified by a

factor of 4 in the output buffer, which can drive a current of up

to 25 mA in a grounded load resistor. The overall rise time of

the AD8310 is less than 15 ns. There is also a delay time of

about 6 ns when the log amp is driven by an RF burst, starting

at zero amplitude.

When driving capacitive loads, it is desirable to add a low value

of load resistor to speed up the return to the baseline; the buffer

is stable for loads of a least 100 pF. The output bandwidth can

be lowered by adding a grounded capacitor at BFIN. The time-

constant of the resulting single-pole filter is formed with the

3 kΩ internal load resistor (with a tolerance of 20%). Therefore,

to set the −3 dB frequency to 20 kHz, use a capacitor of 2.7 nF.

Using 2.7 μF, the filter corner is at 20 Hz.
