ST8024
Pin configuration
5/30
20
RSTIN
Card Reset Input from MCU
21
VDD
Supply Voltage
22
GND
Ground
23
OFF
Interrupt to MCU (active Low)
24
XTAL1
Crystal or external clock input
25
XTAL2
Crystal connection (leave this pin open if external clock is used)
26
I/OUC
MCU data I/O line (internal 11k
Ω pull-up resistor connected to VDD)
27
AUX1UC
Non-inverting Receiver Input (internal 11k
Ω pull-up resistor connected to VDD)
28
AUX2UC
Non-inverting Receiver Input (internal 11k
Ω pull-up resistor connected to VDD)
Table 1.
Pin description
Pin N°
Symbol
Name and function
