Silicon NPN Power Transistor
3DA752
www.iscsemi.com
2
ELECTRICAL CHARACTERISTICS （TC=25℃ unless otherwise specified）
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP.
MAX UNIT
VCE(sat)-1
Collector-Emitter Saturation Voltage
IC= 2A; IB= 200mA
0.8
V
VCE(sat)-2
Collector-Emitter Saturation Voltage
IC= 1.5A; IB= 30mA
2.0
V
V(BR)CBO
Collector-Base Breakdown Voltage
IC= 100uA; IB= 0
40
V
V(BR)CEO
Collector-Emitter Breakdown Voltage IC= 10mA; IB= 0
30
V
V(BR)EBO
Emitter-Base Breakdown Voltage
IE= 1mA; IC= 0
5
V
ICBO
Collector Cutoff Current
VCB= 40V; IE= 0
0.1
μ
A
IEBO
Emitter Cutoff Current
VEB= 5V; IC= 0
0.1
μ
A
hFE
DC Current Gain
IC= 0.5A; VCE= 2V
100
400
COB
Output Capacitance
IE= 0; VCB= 10V; f= 1.0MHz
13
pF
fT
Current-Gain—Bandwidth Product
IC= 500mA; VCE= 5V
120
MHz
hFE-1 Classifications
O
Y
G
100-200 160-320 200-400
