Manufacturer

USA Distributor & Support Center

Representative

DIGITAL-LOGIC AG

Advanced Digital Logic, Inc.

Nordstrasse 4/F

4411 Morena Blvd., Suite 230

CH-4708 Luterbach

San Diego, CA 92117-4328

Switzerland

P: 858.490.0597 F: 858.490.0599

Email: sales@adlogic-pc104.com

http://www.adlogic-pc104.com

Technical Specifications

msme104 rev11/01

Features

Functions

Remarks

General

LAN-Controller

SMC91C94

Memory

64 kBytes

Interfaces

LAN

Ethernet IEEE802.3

I/O Address

Software selectable 300 - 3F0

IRQ

5, 9, 10, 11 selectable

I/O Ports

LAN

10BASE-2 & 10BASE-T

Custom BIOS

Down loadable into Flash BIOS

Driver

ODI, UNIX, NDIS, NT3.5, Novell

Electrical

Power Supply

+5VDC, 250mA

- 9V

generated on-board

Environment

Dimensions

3.8 x 3.6 x 0.8 (96x90x20mm)

Bus

PC/104

104 stack through

Operating Temperature

-13ºF to +158ºF (-25ºC to +70ºC)

Storage Temperature

-85ºF to +257ºF (-65ºC to +125ºC)

MSME104R
