Mounting assembly

I For chassis mounting1) or printed circuit boards

I The set comprises a yoke and a base plate

I Fixing nuts M3 and washers are supplied

Yoke

I Material: Brass clamping yoke (

∅ 3 mm) with thread

Base plate

I Material: Aluminum (0,6 mm)

Ordering code

Complete mounting assembly including nuts and washers

B65647-A2000

FPM0006-4

59 0,2

50,8±0,1

ø3,5+0,15

47,8+0,3

51,8+1

1) On a chassis the coil former must be mounted with its solder pins upward.

B65647

Accessories

PM 50/39
